Manufacturer: Finish Thompson
Series: FTI MSDB
The following powers are valid for 2-pole (2900 rpm) motors.
Impeller diameter: 102 mm (smallest available)
Max. delivery: 12.2 m³/h @ 2 m
Max. head: 31 m @ 0.23 m³/h
Recommended duty point: 6.5 m³/h @ 20 m
Max. pump housing pressure: 9.3 bar
Transportable liquid characteristics:
- max. solids concentration: 10 wt%
- max. sludge particle size: 0.1 mm
- max. individual particle size: 0.4 mm
- max. particle hardness: 80 HS
- max. temperature: 104 °C
Material of parts in contact with liquid:
- housing: PVDF (black)
- connection: FRP flange
Complies with ANSI 150 and PN20/40 counter flange
- bushing: carbon
- o-ring: Viton (FKM)
Connection size:
- suction: 1
- discharge: 1
ATEX: II 2GD, Ex h IIC T6...T4 Gb, Ex h IIIC T6...T4 Db
Connectable IEC motor size and design:
IEC132/B14 (5,5 and 7,5 kW)
Comment:
- the model can be ordered with a different impeller size, more suitable for the expected operating points. This may modify the motor connection and motor power. In order to make a choice, in addition to the operating range, the density of the liquid must also be known.
- the factory provides a 5-year warranty for manufacturing defects, this does not apply to flexible and wearing parts
